Electrical and Electronics Lab
Welcome to the heart of innovation - the Electrical and Electronics Lab within our MakerSpace! This dynamic space is where ideas spark to life, circuits hum with creativity, and experimentation knows no bounds.
Lab Overview
Welcome to the heart of innovation - the Electrical and Electronics Lab within our MakerSpace! This dynamic space is where ideas spark to life, circuits hum with creativity, and experimentation knows no bounds.
Overview:
Our Electrical and Electronics Lab is equipped with cutting-edge tools and resources to support a wide range of projects, from basic circuitry to advanced electronic prototyping. Whether you’re a novice or a seasoned engineer, you’ll find everything you need to bring your ideas to fruition.
Key Features:
State-of-the-Art Equipment: Explore our extensive collection of electronic components, instruments, and devices, including oscilloscopes, signal generators, soldering stations, and more.
Prototyping Stations: From breadboards to PCB fabrication facilities, we provide ample space and resources for designing and testing electronic circuits and systems.
Workstations: Comfortable workbenches equipped with power supplies, magnifying lamps, and ergonomic tools ensure a conducive environment for hands-on experimentation.
Access to Software: Gain access to industry-standard software tools for circuit design, simulation, and PCB layout, empowering you to translate your ideas into tangible prototypes seamlessly.
Expert Support: Our team of experienced technicians and instructors is on hand to offer guidance, troubleshooting assistance, and mentorship throughout your projects.
What you get
Lab Equipment
SUNY-ZGK300 is an entry-level through-hole plating system used to deposit a conductive copper layer through PCB drilled holes, enabling double-sided and multilayer PCB prototyping in-house.Typical use: conditioning, activation,…
The Tektronix TBS1072B-EDU is a 70 MHz, 2-channel digital storage oscilloscope built for university teaching labs. It offers a 1 GS/s sample rate, 2.5k-point record length, 16 automated…
The UNI-T UTP3315TFL-II is a triple-output programmable linear DC power supply with two adjustable channels (0-30 V / 0-5 A) plus a fixed 5 V / 3 A…
The UNI-T UTG2122B is a dual-channel arbitrary waveform / function generator with 120 MHz sine output, 14-bit vertical resolution and a sample rate of 500 MSa/s. It supports…
Lab Equipment
Tools available in this facility. Request access through Contact - online booking is Phase 2.
SUNY-ZGK300 is an entry-level through-hole plating system used to deposit a conductive copper layer through PCB drilled holes, enabling double-sided and multilayer PCB prototyping in-house.Typical use: conditioning, activation,…
The Tektronix TBS1072B-EDU is a 70 MHz, 2-channel digital storage oscilloscope built for university teaching labs. It offers a 1 GS/s sample rate, 2.5k-point record length, 16 automated…
The UNI-T UTP3315TFL-II is a triple-output programmable linear DC power supply with two adjustable channels (0-30 V / 0-5 A) plus a fixed 5 V / 3 A…
The UNI-T UTG2122B is a dual-channel arbitrary waveform / function generator with 120 MHz sine output, 14-bit vertical resolution and a sample rate of 500 MSa/s. It supports…
An entry-level digital storage oscilloscope from RS PRO (RS catalogue stock no. 124-1987). It provides multi-channel signal capture, FFT, automatic measurements, USB host/PC connectivity and a colour LCD…
The Fluke 117 is a true-RMS digital multimeter built for electricians and electronics technicians. It features a 6,000-count display, non-contact voltage detection (VoltAlert), AutoVolt automatic AC/DC selection, low-input-impedance…
SUNY-ZDW300 is an optical alignment / registration table used to align top and bottom artwork (or inner layers) precisely on a PCB before lamination or exposure, ensuring accurate…
SUNY-ZCX301 is a frame / chemical cleaning station that pairs with the spray etching, imaging, and stripping units in the SUNY PCB line, used to rinse and clean…
SUNY-ZCX300 is a hot-air solder leveling / tin immersion plating tank used to deposit a thin tin layer on PCB pads for solderability and corrosion protection.Typical use: immersion-tin…
SUNY-ZFS300 is a closed spray etcher that applies a heated etchant (typically ferric chloride or cupric chloride) under pressure to remove unwanted copper from PCBs after the photoresist…
SUNY-ZXY300 is a spray developing machine used after UV exposure to develop dry-film photoresist on PCBs by spraying a sodium / potassium carbonate solution at controlled pressure and…
SUNY-ZFM300 is a heated roller laminator used to apply dry-film photoresist to copper-clad laminates uniformly and bubble-free, a key step in high-quality PCB prototyping.Typical use: laminate dry-film photoresist…
SUNY-ZBG320 is a UV exposure unit for photo-imageable solder mask and dry-film photoresist on PCBs. A vacuum or pressure frame holds the artwork in tight contact with the…
The HP LaserJet P2055d is a monochrome laser printer rated up to 35 ppm with automatic duplex (two-sided) printing. In a PCB lab it is most often used…
SUNY-ZHG200 is a forced-air dryer / curing oven used between PCB process steps (after cleaning, etching, screen printing) to dry boards and cure photoresist or solder mask coatings…
SUNY-ZSY200 is a manual / semi-automatic PCB screen printer used to apply solder mask and silkscreen layers onto printed circuit boards. It supports common board sizes used in…
The SUNY-ZCB200 is a precision PCB substrate cutter designed for cleanly sizing copper-clad laminates and PCB blanks. It uses a guillotine-style blade with a calibrated stop for repeatable…
SUNY-ZTM300 is a spray stripping machine used to remove the remaining photoresist film from PCBs after etching, leaving clean copper traces ready for finishing.Typical use: strip remaining photoresist…
The Weller WT 1012 (WT1012M) is a 95 W single-channel digital soldering station from Weller's WT Tools line, paired with a WTP 90 soldering iron. It offers fast…
The HAKKO FA-400 is a desktop solder fume absorber that pulls solder fumes through an activated-carbon filter to keep the bench air clean during soldering and rework.Typical use:…
The NXP OM13080UL is the LPCXpresso55S69-EVK development board (Cortex-M33 dual core with TrustZone). It supports IDE workflows in MCUXpresso, Keil, IAR or VS Code and is used to…
The Silicon Labs SLSTK2010A is the EFM32 Wonder Gecko Starter Kit, used at expert level to teach low-power embedded systems, RTOS, energy profiling and Bluetooth / Sub-GHz communication.Typical…
The Easyelec ST-1500 is a 1500 W toroidal step-down voltage converter from 220 V to 110 V (with surge protection on some variants), used to power North American…
A 4 MP indoor IP CCTV camera with H.265 compression, IR night vision, motion detection, two-way audio (model dependent) and PoE / wireless connectivity. Pairs with the lab…
Software
Software tools for this facility are introduced during orientation and training sessions.
Gallery
Rules & Safety
- Complete the lab orientation before your first session.
- Wear required PPE for the equipment you operate.
- Book equipment time in advance via the lab calendar.
- Clean your station and return tools to their dock.
- Report incidents or damaged equipment to a lab steward.
